型號Model

MD-PL36W-R

光源Lighting source

Lumenmax SMD4014 LED or SMD2835

燈珠類型 LED TAPE

SMD4014 LED or SMD2835

總功率Power consumption

36W or 40W （includes driver）

電源輸入電壓

Input voltage (Driver)

90--265VAC /50-60HZ

燈具輸入電壓

Input voltage (Lighting)

35V - 38V DC

輸出電流Constant current

930mA ±5%

電源效率Efficiency

≥85%

電源功率因數PF

≥0.90

光源平均壽命LED Lifespan

≥ 20000H

色溫CCT

2800~6500K

光通量Luminous

3200Lm (±5%)

發光效率Luminescence efficiency

85 lm/w

照射角度Bean-angle

120 °

顯色指數Ra

Ra ≥ 80

發射功率Transmission power

Max6dBm TYP 2dBm

接收靈敏度Receiving sensitivity

-87dBm（FEC OFF）

遙控距離Remote control distance

＞30M

無線發射頻率Wireless transmission frequency

2400-2482MHZ（2.4GHZ）

調光功能 Dimming function

無級調光,1%-100%范圍之間無頻閃

Stepless adjustable light, no stroboscopic between 1% to 100% range

調色溫功能 Color temperature function

無級調色溫,2800-6500K范圍之間無頻閃

Is the color temperature, no stroboscopic range between 2800-6500K

WiFI智能控制 WiFi Control

支持Android / IOS點對點或遠程操作

Support for Android/IOS point-to-point or remote operation

燈殼溫升Temperature rising

< 20 ℃

工作溫度Operation temperature

-15~+50℃

相對濕度Relative humidity

10%-80%RH

燈體材料Fixture Material

Oxidized Aluminum + High Quality PMMA (Acrylic)+PC diffuser

噴砂氧化鋁+亞克力導光板+PC擴散板

尺寸Dimension

595 x 595 x 9.0(10)mm

凈重Net Weight (includes driver)

3.6KG

防護等級Protection grade

IP44

電氣絕緣等級Insulation class

CLASS II

環保Environmental

All materials meet with RoHS compliance /所有材料符合RoHS環保標準

通過認證Certificate

CE, RoHS
